トーション機でのフック・直線部のないコイリング加工 Coiling with No Hooks, No Straight Ends by Torsion Machine
トーション機でのフック・直線部のないコイリング加工 Coiling with No Hooks, No Straight Ends by Torsion Machine
該当機械 Applicable machine
プレゼン Presentation
-
トーション機による直線部、フックのないコイリング加工
Coils without straight ends nor hooks by Torsion Machine
View More -
XYZ3次元スライドとWスピンドルで多彩な加工を実現
XYZ 3D Slides and W spindle tools for versatile maufacturing
View More
解説 Explanation
トーション機ZF40による両端に直線部のないフックなしコイリング。前はハサミ切断による先端の切り飛ばし、後ろは、右スライドによるガイド切断を行っています。
No-hook coiling without straight ends by Torsion Machine, ZF40. The front straight end is cut away by the scissors cutter, and the rear end is cut by the right slide and the edge of the final wire guide.
